Grade A Head Gasket - Replacement for Bobcat 7030334

This Grade A Head Gasket is a replacement for Bobcat OEM 7030334. A low cost, high quality aftermarket part designed to meet or exceed OEM quality.

Details:

• Is 1 hole, 0.077 mm thickness designed for the engine cylinder head.
• Previous part number was 7030335.
• Order this part and the following part, and follow the procedure for a complete replacement:
• Grade C Head Gasket, 7030336
• Procedure:
• The head gasket thickness needs to be correct. Typically there are three thicknesses available and they have a visual identifier (1, 2, or 3 holes).
• The head gasket thickness is chosen by measuring piston protrusion. Each piston needs to be measured at top dead center. Measure the piston at 2 points, making sure you are not measuring in the valve relief areas, and average the readings.
• Once done, average all 4 piston numbers and choose gasket from the table.

Compatible with the following Bobcat Models:

• Compact Excavators: E42, E45, E50, E55, E85, E57W
• Compact Track Loaders: T450, T550, T590, T595, T630, T650
• Skid Steer Loaders: S510, S530, S550, S570, S590, S595, S630, S650
• Toolcats: 5600, 5610
